Last year, Thorne & Derrick were appointed as official distributors of MARECHAL® plugs and sockets in the UK.
Our demonstrated knowledge and expertise in the industry enable us to deliver the complete MARECHAL® product offering in both Industrial and Hazardous Areas.
Below, we focus on the Single Pole Connector range and its features and benefits.
SINGLE POLE CONNECTORS
SAFETY, PERFORMANCE AND ROBUSTNESS
MARECHAL® high current connectors are available in various models and sizes designed for different industrial and hazardous areas.
Marechal single pole connectors are known for their durability, reliability, and ease of use. They are designed to withstand harsh & high risk environments, provide secure connections, and ensure worker safety.
RESISTANCE TO HARSH AND SEVERE ENVIRONMENTS
Materials in poly with IK09 or metal with IK10 that resist to the most demanding environments (corrosion, mechanical shocks, vibrations and electromagnetic disturbances).
MAXIMUM DUST AND WATER RATINGS
All single pole connectors in this particular range of plugs & sockets have an IP66/IP67 rating, offering total protection against humid and dust-loaded environments.
ENHANCED SAFETY
No access to live parts (IP2X), double electrical and mechanical interlocking which prevents any inadvertent disconnection.
OVERLOAD PROTECTION
Designed to accept greater capacity of frequent overloads, as many as 10 times their nominal current rating value, i.e. 12,500 A.
CS1000 500A
- 500A
- 1000 V AC / 1500 V DC
- IP66 / IP67
- Cables from 50sqmm to 400sqmm
- POLY
- IK08
SP 750A
- 750A
- 1000 V AC / 1500 V DC
- IP66 / IP67
- Cables from 50sqmm to 630sqmm
- POLY
- IK08
DSP400 400A
- 400A
- 500 V AC / 750 V DC
- IP66 / IP67
- Cables from 50sqmm to 300sqmm
- POLY or METAL
- IK09
- EMC
DSP1250 1250A
- 1250A
- 1000 V AC / 1500 V DC
- IP66 / IP67
- Cables from 50sqmm to 630sqmm
- METAL
- IK10
- EMC
SPeX 680A
- 680A
- 1000 V AC / 1000 V DC
- IP65 / IP66
- Cables from 50sqmm to 630sqmm
- ATEX II 2 G D Ex e IIC, Ex tb IIIC
- GRP
- IK08
APPLICATION SPOTLIGHT - DATA CENTRES
Marechal® plugs and sockets are high-performance electrical connectors that are commonly used in data centres and other industrial applications. They are designed to provide a secure and reliable connection for power distribution and equipment connections.
Marechal DSN3
Marechal EVO 40
DSN3 can be used to input power supplies for the UPS units inside the data centre. During maintenance of the UPS, located below the removeable flooring system of the data centre, the quick, safe, and easy disconnection / connection features and its compact size, makes the DSN3 the perfect solution.
EVO 40 electrical connector is commonly used for hot swappable servers, allowing for easy and safe connection and disconnection of servers without the need to power down the entire system. It is designed to handle high current loads, so it is suitable for server cabinets where power requirements can be substantial.
Thorne & Derrick International are the Leaders in ATEX & IECEx Product Innovation providing lighting, heating, ventilation and power distribution in Explosive Atmospheres. Talk to us today about how we can improve safety, energy efficiency and productivity in your hazardous areas.
