ATEX Ammeter Red Pilot Light | Zone 1 & Zone 2 Hazardous Area | ATX U42W2A5A9

ATX U42W2A5A9 – Ammeter with Red Pilot Light for Zone 1/2

The U42W2A5A9 model is a dual-function control station combining a 48mm x 48mm ammeter with a red pilot light. It is purpose-built for real-time electrical monitoring in hazardous zones where ATEX compliance is mandatory.

Features:

Appleton ATX Twin Push Button

ATX U42W2A5A9

  • Ammeter: 0–5A scale (1A C.T. / 5 F.L.C.)

  • Pilot Light: 1x Red Light for status indication

  • Explosion Protection: Ex de IIC / Ex demb IIC / Ex tD A21

  • Area Use: Zones 1/2 (Gas) and 21/22 (Dust)

  • Enclosure Rating: IP66 | IK09

  • Cable Entries: 2 x M20 bottom

  • Weight: 0.80kg

  • Enclosure Volume: 2.5dm³

A compact and powerful unit for electrical diagnostics and signal feedback in hazardous industrial environments.

Hazardous Area Lighting Control Station Plug Junction Box

Lighting | Control Stations | Plugs & Sockets | Junction Boxes | Hazardous Area ATEX Certified Electrical Equipment for Explosive Atmospheres | Zone 1 & Zone 2
