Hazardous Area IS Ultrasonic Sensor (ATEX IECEx UL)

Deeter RPS-409A-IS2 is hazardous area ultrasonic sensor that can be used in hazardous gas or dust environments classified as Zone 0, 1, 2, 20, 21, or 22 for ATEX/IECEx, and Class I, II, or III for UL/cUL when used with approved intrinsic safety barrier(s).

The Deeter RPS-409A-IS2 has built in temperature compensation to provide accurate readings throughout the entire operating temperature range.

The RPS-409A-IS2 is designed to take advantage of today’s PLC and computer analog input cards. The numerical values that are programmed into the PLC or computer will determine the zero and span.

T&D distribute the complete range of Deeter Level Sensors and Float Switches.

Hazardous Area IS Ultrasonic Sensor (ATEX IECEx UL) – Deeter RPS-409A-IS2

Features

  • Intrinsically safe and UL Listed
  • ATEX, cUL, IECEx & ANZEx approvals
  • Wide sensing and temperature ranges
  • Analog voltage output
  • Sync/Tx input line
  • PPS enclosure
  • LED Indicator

Deeter RPS-409A-IS2 Hazardous Area IS Ultrasonic Sensor – Technical Specification

Hazardous Area IS Ultrasonic Sensor Approval & Application Standards Australia and New Zealand – ANZEx 13.3010X Ex ia I Ma, Ex ia IIC T4 Ga, Ex ia IIIC T101°C Da

Canada and USA – UL/cUL File # E226209

CL I, GPS A,B,C,D; CL II, GPS E,F,G; and CL III

Europe (CENELEC) – DEMKO 12 ATEX 1103028X

Ex I M1 / II 1 GD

IECEx – IECEx UL 12.0001X

Ex ia I T4 Ma, Ex ia IIC T4 Ga, Ex ia IIIC T101°C Da

ATEXIECExUL Listed

Power Input 16 – 30VDC Reverse Polarity Protected (A minimum of 24VDC must be applied to the power barrier)
Input Current 24mA maximum with 24VDC applied to the power barrier
Ambient
Temperature
-40 – 60°C or -40 – 140°F
Humidity 0% – 95% Non-Condensing
Housing Polyphenylene Sulfide (PPS) Enclosure with PPS and PTFE sensing face
Output Analog Voltage Output 0-10V
(Load 100k Ohms to infinity)
Short Circuit Protected

DEETER RPS-409A-IS2 HAZARDOUS AREA IS ULTRASONIC SENSOR – Product Range

Hazardous Area IS Ultrasonic Sensor Part Number Description Sensor Range  Transducer Frequency  Response Time Volts Per Inch
Deeter RPS-409A-40-IS2 0 – 10 VDC Analog Output 4″ to 40″ 175kHz 85ms 0.250
Deeter RPS-409A-80-IS2 0 – 10 VDC Analog Output 6″ to 80″ 135kHz 85ms 0.125
Deeter RPS-409A-144-IS2* 0 – 10 VDC Analog Output 10″ to 144″ 70kHz 175ms 0.069
Deeter RPS-409A-216-IS2* 0 – 10 VDC Analog Output 12″ to 216″ 70kHz 175ms 0.046
