Hazardous Area Fluorescent Luminaires – Zone 1 Zone 2 ATEX Fluorescent Lighting

T&D are Main Distributors for Appleton – this includes their full range of Zone 1 and Zone 2 fluorescent luminaires with ATEX & IECEX certification for providing safe and reliable light in potentially explosive atmospheres – we service UK and international projects in the oil, gas, petrochem and general hazardous area industries.

Fluorescent Lighting – Zone 1 & Zone 2 ATEX certified

• Zone 1 Zone 2 (21/22) Lighting – ATEX Fluorescent Luminaires – Appleton FE
• Zone 1 Zone 2 (21/22) Lighting – ATEX Fluorescent Luminaires – Appleton FD
• Zone 1 Zone 2 (21/22) Lighting – ATEX Fluorescent Luminaires – Appleton RE
• Zone 2 (21/22) Lighting – ATEX Fluorescent Luminaires – Appleton FN
• Zone 2 Zone 22 Lighting – ATEX Fluorescent Luminaires – Appleton FL

Appleton	Description	Hazardous Area Lighting	T-Class Rating	Surface Temperature	Explosion Protection	Certification	Power Outputs	Ingress Protection	Impact Resistance
FE	Fluorescent Luminaires	Zone 1 and 2 (Gas) and Zone 21 & 22 (Dust)	T5 T6 types	+75°C	Ex tD A21	ATEX IECEx, NBR IEC	18W, 36W or 58W	IP66/67	IK10
FD	Fluorescent Luminaires	Zone 1 and 2 (Gas) and Zone 21 & 22 (Dust)	T4 T5 T6 types	+78ºC to +130ºC	Ex d IIB / Ex d IIB+H2, Ex d IIC, Ex tD A21	ATEX IECEx, GOST	18W, 36W or 58W	IP66/68	IK08
RE	Fluorescent Luminaires	Zone 1 and 2 (Gas) and Zone 21 & 22 (Dust)	T4 T5 T6 types	+75ºC	Ex de IIC / Ex demb IIC (Emergency version), Ex tD A21	ATEX IECEx	18W, 36W or 58W	IP66	IK09/10
FN	Fluorescent Luminaires	Zone 2 (Gas) and Zone 21 & 22 (Dust)	T4 T5 T6 types	+75ºC	Ex nR II or Ex nA II, Ex tD A21	ATEX IECEx, GOST	18W, 36W or 58W	IP66/67	IK10
FL	Fluorescent Luminaires	Zone 2 (Gas) and Zone 22 (Dust)	T5 T6 types	+75ºC to +91ºC	Ex nR II or Ex nA II, Ex tD A22	ATEX IECEx	18W, 36W or 58W	IP65/67	N/A

➡ For complete specifications, technical details and hazardous area classification on Appleton Hazardous Area Fluorescent Luminaires please refer to the product sections below.
