Plugs & Sockets

Explosion Proof

The ABB range of explosion proof plugs and sockets covers most explosion proof and protection applications.

With Tough & Safe and heavy duty mechanical interlocks, the explosion proof plugs for hazardous areas are suitable for use in most harsh environments with potentially explosive atmospheres in onshore or offshore locations in the oil, gas and petrochemicals industries.

These ATEX plugs & sockets, manufactured by ABB, are used for to connect equipment in all kind of hazardous areas where it needs to be possible to connect and disconnect. ABB plugs and sockets are chosen when safety, reliability and durability is requested.

ATEX Socket Specification

Product: Mechanical Interlocked Socket
Current: 63A Amp
Terminals/Poles: 3P + Neutral + Earth
Voltage: 346-415 V
Frequency: 50 & 60 Hz
Socket Width: 180 mm
Socket Height: 211 mm
Socket Length: 407 mm
Socket Weight: 7.800 kg
Cable Diameter: 16 … 35 mm
Socket Colour: Red
Connection Type: Screw Clamp
Socket Housing Material: Glass-fibre reinforced polyester
Degree of Protection: IP66
Explosion protection – Hazardous Area Zone 1 & Zone 2 Gas: II 2 G Ex de IIC T6 Gb
Explosion protection – Hazardous Area Zone 21 & Zone 22 Dust: II 2 D Ex tD A21 60ºC Db
ABB Socket Type: 463MVS6XW
ABB Order Code: 2CMA101690R1000
