VEGA VEGAFLEX Guided Wave Radar Level Measurement

View Sub Products

Guided Radar Level Measurement

VEGA VEGAFLEX Guided Wave Radar Level Measurement – Hazardous Area Zone 1 & Zone 2 ATEX & IECEx.

VEGA VEGAFLEX guided wave radar level measurement sensors are ideal for applications with a variety of process conditions and with no moving parts, the VEGAFLEX sensors are unaffected by shifts in pressure, temperature, or product specific gravity, making the range reliable for level measurement in potentially explosive atmospheres (hazardous areas) and non-hazardous (safe areas).

Guided wave radar has many benefits over traditional level measurement including no moving parts and easy to configure electronics which  eliminates many of the measurement and maintenance issues associated with traditional methods.

In addition, guided wave radar is not affected by temperature, pressure, or specific gravity shifts, making the technology less susceptible to the measurement errors often associated with capacitance probes and ultrasonic transmitters.

VEGA VEGAFLEX Guided Wave Radar Principle

VEGA VEGAFLEX Guided Wave Radar Principle

In solids applications, the VEGAFLEX is able to reliably measure during the fill and empty cycles, overcoming the common errors seen with ultrasonic sensors.

VEGA vegaflex guided Wave Radar Level Measurement – Product Benefits

VEGAFLEX guided wave radar level measurement sensors are suitable for measuring in a wide range of applications and industries as the instruments are unaffacted by foam, dust, and vapor, making the guided wave principle multi-functional across liquids and solids measurements.

As there are no moving parts, the VEGAFLEX is ideal for retrofitting in mechanical technologies.

VEGA VEGAFLEX level measurement instruments reduce maintenance and installation costs and further cost savings can also be achieved through longer test intervals, as well as faster and simpler tests.

Guided Wave Radar Principle Of Operation

The principle of guided wave radar is a relatively simple, effective method of measuring levels of liquids and some solids.

The VEGAFLEX emits a microwave pulse to the process surface “guided” by a metallic cable, rod, or coaxial tube.

The microwave pulses are reflected from a solid or liquid material. The transit time of the microwave pulse returning to the electronics is measured and used to calculate the distance to the process medium.

VEGA vegaflex Sensors For Hazardous Areas

The full range of VEGA guided radar level measurement sensors is suitable for use in hazardous areas and are manufactured with a wide range of hazardous area certifications. Approvals include ATEX, IEC, FM, CSA, Gost, overfill protection, Ship, SIL2.

Many industries require hazardous area level measurement including food and beverage, chemical, oil and gas, automotive, paper and pharmaceutical.

VEGA Guided Wave Radar Hazardous Area Level Measurement

VEGA Guided Wave Radar Hazardous Area Level Measurement

VEGA VEGAFLEX

Guided Wave Radar Sensors Product Range

VEGA VEGAFLEX range of guided radar level measurement sensors are suitable for measuring in applications with a variety of process conditions. The full range includes:

  • VEGAFLEX 61
  • VEGAFLEX 62
  • VEGAFLEX 63
  • VEGAFLEX 65
  • VEGAFLEX 66
  • VEGAFLEX 67
  • VEGAFLEX 81
  • VEGAFLEX 82
  • VEGAFLEX 83
  • VEGAFLEX 86
  • VEGAPASS 81

VEGA Guided Radar Level Measurement Product Applications & Components

VEGA VEGAFLEX Guided Wave Radar Level Sensor

VEGA VEGAFLEX Guided Wave Radar Level Sensor

VEGA Guided Radar Level Measurement – Instruments For Every Application

The range of VEGA VEGAFLEX guided radar level measurement sensors are tested in extreme conditions including exposure to dust, heat, cold, moisture and chemicals. This ensures operational efficiency and performance in the harshest conditions including safe and hazardous areas.

VEGA Sensors

Sensors, Switches & Transmitters For Continuous Level, Point Level & Pressure Measurement In Process & Hazardous Area Industries (Zone 1 & Zone 2 ATEX & IECEx Certified).

Thorne & Derrick are Process Instrumentation Specialists – contact us about VEGA level sensor equipment, we can provide a full system solution for level measurement and sensing of bulk solids, conductive and non-conductive liquids in industrial and hazardous area locations. For complete technical specifications, ordering information and application details about VEGA VEGAFLEX Guided Wave Radar Level Measurement please browse the product sections below.
