LIGHTING DESIGNS FOR HAZARDOUS AREAS

Upgrading Plant Legacy Lighting to LED

Thorne & Derrick International, based in the UK, are leading Stockists & Distributors of hazardous area lighting products utilising conventional light fittings and more powerful modern technology White-Light illumination using LED technology – from stock we provide competitive prices and lighting design support to enable the specification of explosive atmosphere lighting schemes compliant and certified to international standards including ATEX and IECEx.

Using latest software our FREE Lighting Design Service supports the upgrade from fluorescent to LED lighting focussed on maximised light output, optimised energy consumption with reliable and safe certification for explosion protection concepts in Zone 1 and Zone 2 hazardous area zones and workplaces.

IECEx ATEX

Lighting Design Services


Hazardous Area Lighting

ATEX/IECEx Hazardous Locations & Explosive Atmospheres

Below is a useful selection guide by Appleton ATX to help you select the correct lighting product for your application taking into account the lumen output, equivalency, wattage, efficacy, voltage, CCT/CRI as well as the correct zone classification for hazardous areas.

➡ If you need anymore advice please contact the Thorne & Derrick Lighting Design Team.

Lighting ProductApplicationLumen OutputEquivalencyWattageEfficacyVoltageCCT/CRI
Hazardous Area Classifications: Zone 1, 21 or Zone 2, 21
Areamaster Generation 2 LED Lighting (Zone 1, 21: AMLZ, AMHZ; Zone 2, 21: AMLG, AMLH)
Wattage Efficacy
Areamaster LED Generation 2 and High LumenFloodlight9,000 – 38,000175W – 1500W HID70W – 291W141120 – 277 Vac;
125 – 300 Vdc
3000K/80 4000K/80 5000K/70
Baymaster LED Lighting (Zone 1, 21: BLZ, BHZ; Zone 2, 21: BLL, BHL)
Baymaster LED (Zone 1, 21 BLZ, BHZ Zone 2, 21 BLL, BHL)Highbay9,000 – 38,000175W – 1500W HID70W – 291W141120 – 277 Vac;
125 – 300 Vdc
3000K/80 4000K/80 5000K/70
ATX FELED Light Fittings
FELEDLinear, Emergency3,000 – 7,2001x18W – 3x58W Linear Fluorescent31W – 75W106120 – 277 Vac;
125 – 300 Vdc
4000K/80 5000K/70
ATX FDLED Light Fittings
FDLEDLinear, Emergency400 – 4,,7251x18W–2x36W Linear fluorescent6W-46W103110–254 Vac; 48/110/220 Vdc5000K/70
Mercmaster Generation 3 LED (Zone 1, 21: MGZ; Zone 2, 21: MLG, MLGH)
Mercmaster Generation 3 LED (Zone 1, 21 MGZ Zone 2, 21 MLG, MLGH)Task, High Ambient2,600 – 26,00070W – 1000W HID30W – 210W160120 – 277 Vac;
125 – 300 Vdc
3000K/80 4000K/80 5000K/70
ATX FDBAES LED Light Fittings
FDBAES LEDEscape Only540/55N/A5W110230 Vac5650K/70
ATX DEMULED Light Fittings
DEMULEDEscape Only540/55N/A5W110230 Vac5650K/70
Hazardous Area Classifications: Zone 2, 21, 22
ATX FN LED Light Fittings
FDLEDLinear Emergency3,000 – 7,2001x18W – 3x58W Linear Fluorescent31W – 75W106120 – 277 Vac;
125 – 300 Vdc
4000K/80 5000K/70
ViamasterTM LED (LLEDA) Light Fittings
Viamaster LED (LLEDA)Linear Emergency2,200 – 7,8001x18W – 3x58W Fluorescent22W – 81W100120 – 277 Vac5650K/70
Mercmaster LED Low Profile (MLLED) Light Fittings
Mercmaster LED Low Profile (MLLED)Task2,800 – 5,50070W – 175W HID27W – 50W125120 – 277 Vac; 125 – 300 Vdc3000K/80 4000K/80 5000K/70
ATX FNESLED Light Fittings
FNESLEDEscape Only540/55N/A5W110230 Vac5650K/70

NEC/CEC & ATEX/IECEx Hazardous Locations & Explosive Atmospheres

ProductApplicationLumen OutputEquivalencyWattageEfficacyVoltageCCT/CRI
NEC/CEC Classifications: Class I, Division 2, Groups A, B, C, D; Class II, Division I, Groups E, F, G; Class I, Zone 2 AEX/EX ec IIC; Zone 21 Ex tb IIIC; Class III
ATEX/ IECEx Classifications: Zone 2, 21, 22
Areamaster LED Generation 2 and High Lumen
Areamaster LED Generation 2 and High LumenFloodlight9,500 – 38,000175W – 1500W HIID68W – 317W140120–277 Vac;
125–300 Vdc
347–480 Vac
3000K/80, 4000K/80, 5000K/70
BaymasterTM LED and High Lumen
Baymaster LED (Zone 1, 21 BLZ, BHZ Zone 2, 21 BLL, BHL)Highbay8,700–39,000175W – 1500W HIID68W – 317W140120–277 Vac;
125–300 Vdc
347–480 Vac
3000K/80, 4000K/80, 5000K/70
NEC/CEC Classifications: Class I, Division 2, Groups A, B, C, D; Class II, Division I, Groups E, F, G; Class I, Zone 2 AEX/EX ec IIC; Zone 21 Ex tb IIIC; Class III
ATEX/ IECEx Classifications: Zone 2, 21, 22
Mercmaster LED Generation 3
Mercmaster LED Generation 3Task, High Ambient2,600 – 26,00070W – 1000W HIID30W – 210W149120–277 Vac;
125–300 Vdc
347–480 Vac
3000K/80, 4000K/80, 5000K/70
Mercmaster LED Low Profile
Mercmaster LED Low ProfileTask, High Ambient2,800 – 5,50070W – 1000W HIID27W – 50W125120–277 Vac;
125–300 Vdc
347–480 Vac
3000K/80, 4000K/80, 5000K/70

Thorne & Derrick are leaders in ATEX & IECEx Product Innovation providing Lighting, Heating, Ventilation and Security in Explosive Atmospheres.

Talk to us today about how we can improve operational safety, energy efficiency and optimise productivity in your hazardous areas.

We are your proactive problem solvers experienced in succession planning for the replacement of obsolete, non-conformant and legacy equipment in hazardous areas.

Your first-choice provider of innovative and competitive solutions to ensure ATEX & IECEx Compliance for your UK and international projects.
