Wolf LL-12 Flameproof Leadlamp

Wolf LL-12

Leadlamp

Gas: Hazardous Area Zone 1 & Zone 2

Thorne & Derrick, the Specialist Distributors of Hazardous Area Lighting can provide competitive prices and supply from stock the complete range of Wolf temporary and portable lighting products.

Wolf LL-12 hazardous area inspection leadlamps are ATEX certified for use in Zones 1 & 2 (Gas).

Wolf LL-12 Hazardous Area Leadlamp

Wolf LL-12 is an ATEX leadlamp with “e” increased safety type of protection for hazardous areas – using halogen as the light source the LL-12 provides an output of 55W.

Part Number: Wolf LL-12
Product Category: Hazardous Area Lighting
Product Range: Hazardous Area Inspection Leadlamps
Description: High Power Halogen Floodlight Leadlamp
Hazardous Area Code: II 2 G EEx d e IIC T3/T4
Explosion Proof/Protection Concept: “d” flameproof, “e” increased safety
Hazardous Area Classification (Gas): Zones 1 and 2, Gas Groups IIA, IIB, IIC
Temperature Classification (Gas): T4
Ambient Temperature: -20°C to +40°C
Certificate: BVS 03 ATEX E 279
Enclosure: Light Alloy, High Impact Plastic, Oil Resistant Rubber
Lens: Toughened Glass
Beam Type: 100° Wide Angle Flood
See more ATEX Leadlamps

Light Source

Type: Tungsten Halogen Filled Filament Bulb
Bulb Life: Up to 1000hrs

Light Output

55w with Flood Beam (approx 100°) / Peak Luminous Intensity at 5m 180 lux

➡ See our technical resource section for further detailed information about hazardous area Zones and T-Class ratings.

Wolf ATEX Flameproof Leadlamp for use in potentially explosive atmospheres and is CE marked to the ATEX Directive for safe use in zone 1 and 2 potentially explosive gas atmospheres.

ATEX Certification: II 2 G EEx d e IIC T3/T4

Wolf LL-12 – Spot Beam (approx 100°) – for further information about Hazardous Area Lighting for Zone 1 and Zone 2 please contact T&D’s Sales Engineers.

➡ For complete specifications, technical date and ordering details about Wolf LL-12 please refer to the download opposite or contact T&D to discuss your torch requirements.

WOLF ATEX FLAMEPROOF LEADLAMP TECHNICAL INFORMATION

The following table explains the technical specification differences for the Wolf ATEX flameproof range of leadlamps – should you require support or advice on selecting the correct hazardous area leadlamps please do not hesitate to contact us.

Wolf LL-12

Wolf ATEX Flameproof Part Reference		Wolf LL-12
Product Designation		KHLE 70 EN
Leadlamp Description		High Power Halogen Floodlight Leadlamp
Hazardous Area Code (ATEX & IECEx)		II 2 G EEx d e IIC T3/T4
Equipment Category		2G
Type of Protection		“d” flameproof, “e” increased safety
Area of Hazardous Classification (Gas)		Zones 1 and 2, Gas Groups IIA, IIB, IIC
Temperature Classification (Gas)		T4
Ambient Temperature		-20°C to +40°C
ATEX Certificate		BVS 03 ATEX E 279
Enclosure		Light Alloy, High Impact Plastic, Oil Resistant Rubber
Lens		Toughened Glass
Light Source	Wolf ATEX Flameproof Part Reference	Wolf LL-230
	Type	Halogen Filled Filament Bulb
	Voltage	12v
	Watts	55w
	Beam	100° Wide Angle Flood
	Life	Up to 1000hrs
Power Source	Insulation	Class lll
	Voltage	12 Vac/dc
Weight		2.5kg (excluding cable)
Ingress Protection		IP54 minimum

Wolf LL-12 Flameproof Leadlamp

Wolf – tHE hAZARDOUS AREA lIGHTING sPECIALISTS

Handheld straight and right-angled torches, headtorches, handlamps including the market-leading Wolflite Handlamp with bulb and LED versions for safe lighting in hazardous area Zones 0, 1 and 2 gas and Zones 20, 21 and 22 dust explosive atmospheres – T&D provide competitive prices and delivery for the complete range of Wolf Lighting.

Contact T&D to discuss all your portable and temporary hazardous area lighting requirements – as Main Distributors for Wolf Safety Lamp we can provide expert technical support and competitive prices with delivery from stock.
