Petrel Lighting, Motor Starters & Isolators (Hazardous Area Zone 1 & Zone 2 ATEX)

Petrel - Hazardous Area Zone 1 & Zone 2 Lighting, Motor Starters & Isolators (ATEX)

Hazardous Area Zone 1 & Zone 2 Lighting, Motor Starters & Isolators (ATEX)

Petrel manufacture Hazardous Area Lighting, Motor Starters, Isolators & Enclosures for hazardous area locations Zone 1 & Zone 2 certified according to ATEX directive.

Ex d (flameproof) explosion protected lighting provides reliable, safe and highest quality light levels for use in the oil, gas and petrochemical industries.

Hazardous Area Lighting

Petrel

Zone 1 Hazardous Area Lighting – ATEX Certified

Petrel Lighting

Hazardous area lighting luminaires including linear, wellglass, floodlight and bulkhead lights certified by ATEX for Zone 1 lighting.

  • 9 Series Ex ed Zone 1 Fluorescent Luminaire (ATEX) 18W to 58W Lamps – Linear Light Fittings

    ATEX Lighting

    ATEX Lighting

  • 9 Series Ex ed Zone 1 LED Luminaire (ATEX) – Linear Light Fittings
  • 7 Series Ex d Zone 1 Fluorescent Luminaire (ATEX) 8W to 58W Lamps – Linear Light Fittings
  • 7 Series Ex d Zone 1 LED Luminaire (ATEX) – Linear Light Fittings
  • 8 Series Ex de Zone 1 Floodlight (ATEX) – 150W to 500W Lamps
  • Pd9000 LED Floodlight – Zone 1 Hazardous Area (ATEX)
  • 6 Series (610) Ex de Zone 1 Hazardous Area Well Glass Light Fitting (ATEX)
  • 6 Series (620) Ex de Zone 1 Hazardous Area Well Glass Light Fitting (ATEX)
  • 6 Series (621) Ex de Zone 1 Hazardous Area Bulkhead Light Fitting (ATEX)
  • 9 Series Recessed Ex de Zone 1 Fluorescent Luminaire
  • Portable Luminaire Fluorescent & LED – Zone 1

More info: Zone 1 Hazardous Area Lighting

Petrel 9 Series Ex ed Zone 1 LED Luminaire (ATEX) - Linear Light Fittings

Zone 1 Hazardous Area Lighting – Standard & Emergency Fluorescent Luminaires (ATEX Certified). Petrel 9 series light fittings with twin 18w, 26w or 58w lamp tubes.

Zone 1 Hazardous Area Lighting

Zone 1: Petrel Bulkhead, Fluorescent Fitting, Well Glass, Floodlights & LED Luminaires – all ATEX Certified for hazardous area Zone 1 lighting.

Zone 2 Hazardous Area Lighting – ATEX Certified

Petrel Lighting

Hazardous area lighting luminaires including linear, floodlight and bulkhead lights certified by ATEX for Zone 2 lighting utilising high power LEDs and traditional fluorescent single and twin lamps (18w, 36w and 58w).

More info: Zone 2 Hazardous Area Lighting

DN Series EX nR Bulkhead Luminaire (Up to 200W Lamps) - Zone 2 Hazardous Area ATEX Certified

Zone 2 Hazardous Area Lighting: Petrel DN Series EX nR Bulkhead Luminaires.

Zone 2 Hazardous Area Lighting

Zone 2: Petrel LED Luminaire, Fluorescent Luminaire, Floodlights & Bulkheads – all ATEX Certified for hazardous area Zone 2 lighting.

Hazardous Area Lighting

Zone 1 Enclosures, Motor Starters & Isolators – ATEX Certified

Zone 1 Enclosures, Motor Starters & Isolators - ATEX Certified

Flameproof Enclosures: Exd certified cast (aluminium or iron) explosion proof enclosures for hazardous area locations.

Petrel G20 hazardous area certified Exd certified cast (aluminium or iron) explosion proof enclosures suitable for use in Zone 1 and Zone 2 applications. Custom designed hazardous area control panels are available to cover a wide variety of gas groups and temperature classes.

Ex d flameproof electrical enclosures with ATEX certification house a variety of control equipment. Hazardous area motor starters rated 5.5kW to 55kW with or without isolators

How To Select Hazardous Area ATEX Enclosures

T&D can provide standard and customised electrical enclosures – contact us to discuss your requirements.

  • Kilowatt Rating
  • Hazardous Area Gas Group, Zone & T-Class Rating
  • Current Loading
  • Cable Entries – cable size and number
  • Terminals – size and number
  • Voltages & Frequencies
  • Motor Starter Type – DOL, Star Delta, Reversing, 2 Speed
  • Switch Type – number of poles and current rating
  • Button – number and type

More Info: Zone 1 & Zone 2 Enclosures, Motor Starters & Isolators

ATEX, Hazardous Area Zones & Gas Groups

Typical hazardous area lighting and electrical equipment markings:

Ex II 2 G, Ex II 3 D

Where II is the equipment group; 2 is the category for use; G (or D) is the type of explosive atmosphere – G = gas, vapour or mist; and D = Dust

IIC T4 Ta = -20°C to  + SS°C

IIC refers to the gas group (potentially explosive atmosphere) and where the T class (temperature rating) will vary against ambient

IIC TS Ta = -20°C to  + 2S°C

T class marking for dust may also be shown if different to gas

The hazardous area location classification and corresponding equipment categories are – Category 1 equipment can also be used in hazardous area Zones 1 and Zones 21 and Category 1 and 2 equipment can be used in Zones 2 and Zones 22.

  • Zone 0 & Zone 20 – Category 1 Equipment
  • Zone 1 & Zone 21 – Category 2 Equipment
  • Zone 2 & Zone 22 – Category 3 Equipment
ATEX Hazardous Area Lighting Zone 1 Zone 2

T&D UK & Exports support worldwide oil, gas and petrochemical projects with an extensive range of Hazardous Area Lighting, Motor Starters & Electrical Enclosures.

Hazardous Area Zone 1

A hazardous area location in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is likely to occur in normal operation occasionally.

Hazardous Area Zone 2

A hazardous area location in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is not likely to occur in normal operation but, if it does occur, persists for a short period only.

T&D, The Explosive Atmosphere Experts, can confidently specify and supply hazardous area lighting, electrical enclosures, motor starters and isolators. Contact us to discuss your requirements for Zone 1 & Zone 2 hazardous area locations – we distribute the most extensive range of Electrical, Mechanical, Process & Instrumentation Equipment.



How T&D Can Help YouConstruction

Since 1985 T&D have serviced the UK and world markets with an extensive range of Electrical, Mechanical, Process & Instrumentation Equipment – our Export Department is staffed by a team of professional sales engineers, sourcing specialists, expeditors and customer service advisors.

T&D global project experience has enabled us to build a solid reputation for the reliable supply of brand leaders – we consolidate your supply chain by providing single-source logistics to any international destination.
