Zone 2 Floodlight Hazardous Area Lighting ATEX Certified – Petrel ZT

Zone 2 Floodlight ATEX - Petrel ZT

Zone 2 Floodlight ATEX – Petrel ZT

Zone 2 Hazardous Area Floodlight

ATEX Classification – Ex nR II 3GD T3 (T4 for 150W SON version)

Petrel ZT medium duty floodlights are suitable for Zone 2 hazardous area lighting – manufactured from die cast aluminium with built in symmetrical reflector as standard.

Zone 2 floodlight can be fitted with a range of control gear that is suitable for lamps from 150W to 500W and can be used with SON, MBF and tungsten lamps for hazardous area lighting. Access to the lamp and control gear is via a hinged front cover. Floodlight can be mounted using adjustable pivot bracket – Zone 2 bulkhead light fittings for hazardous areas are also available.

➡ View full range of hazardous area lighting.

Please Note: This range has been superseded by Zone 2 LED Area Light

Hazardous Area Zone 2 Lighting - Floodlight

Zone 2 Hazardous Area Lighting For Potentially Explosive Atmospheres In Both Onshore & Offshore Locations

Zone 2 Floodlight

ATEX CERTIFICATION & APPROVAL

Hazardous Area Lighting

Hazardous Area Zone 2 Lighting Stockists & Suppliers Shipping Worldwide

  • Certification and Hazardous Area Approval Certification Code: Ex nR II 3GD T3 or T4
  • Certification Number: 05 ATEX TFZT/01
  • Certification Standard: EN 60079-0, 15
  • Floodlight Protection: IP 66

ZONE 2 FLOODLIGHT – BENEFITS & OPTIONS

  • Floodlight features symmetrical reflector allows maximum directional light output
  • Graduated mounting bracket allows for consistent installation angle for multiple units
  • Easy re-lamping via hinged front section
  • Sodium, metal halide, and tungsten lamp options for Zone 2 hazardous area
  • 230v 50Hz standard
  • -20°C to +30°C standard supply subject to ambient temperature requirements
  • Tubular: SON, MBI, Tungsten. 70w to 500w Symmetrical reflector fitted to all versions. (Lamps not provided)
  • Floodlights available in other colours
  • Petrel Floodlight ZT150 (150W SON), ZT250 (250W SON), ZT400 (400W SON)
  • Petrel Floodlight ZT500 (500W tungsten halide)
Zone 2 Floodlights ATEX - Petrel ZT

Zone 2 Floodlights ATEX Certified For Hazardous Area Lighting – Petrel ZT

Zone 2 Floodlights ATEX Certified

Petrel ZT Technical Data

Supply Voltage 230v 50Hz standard
Operating Temperature -20°C to +30°C standard supply subject to ambient temperature requirements
Control Gear Integral within the luminaire and optional power factor correction when fitted
Floodlight Lamp Options Tubular: SON, MBI, Tungsten. 70W to 500W symmetrical reflector fitted to all versions (Lamps not provided with floodlight)
Cable Entries Terminals 1 x M20 clearance hole in side of body. 2 wire and earth. Cable size 4mm² max
Mounting Facility “U” shaped stirrup bracket with angle adjustment mechanism.
Access Unscrew 2 stainless steel screws in hinged glass retaining frame.
Material Corrosion resistant die cast aluminium and toughened glass lens.
Finish 2 Pack epoxy paint on primed surface. Standard floodlight colour – Aqua. Additional costs for non standard colours
Weight 19.5Kgs to 21Kgs Lamp dependent
Zone 2 Floodlights ATEX - Petrel ZT - Dimensions

Zone 2 Floodlights ATEX – Petrel ZT – Dimensions

Zone 2 Floodlights ATEX - Hinged Lend Opening

Zone 2 Floodlights ATEX – Hinged Lend Opening

Zone 2 Floodlights ATEX - Cable Entry & Termination Block

Zone 2 Floodlights ATEX – Cable Entry & Termination Block

Zone 2 Floodlights ATEX - Adjuatable Angle Mounting Stirrup

Zone 2 Floodlights ATEX – Adjuatable Angle Mounting Stirrup
