The Abtech Avena is a Stainless Steel Ex nR street light, designed for use in Zone 2 & 22 hazardous areas. The Zone 2 Street Light features efficient optical design and five position lamp adjustment for optimum horizontal distribution.

The internal control gear suitable for both High Pressure Sodium and Metal Halide lamps. A timed ignitor is also fitted as standard.

Dependent upon wattage the Abtech Avena comes in two sizes making it ideal for roads, walkways and perimeter lighting.

Zone 2 Street Light ATEX IECEx Ex nR Hazardous Area – Abtech Avena

Zone 2 Street Light ATEX IECEx Ex nR Hazardous Area – Abtech Avena

Zone 2 Street Light ATEX IECEx Ex nR

Features

  • Internal control gear suitable for both High Pressure Sodium and Metal Halide lamps
  • Timed Ignitor as standard
Luminaire TypeZone 2 road lantern
Ingress ProtectionIP65 to EN60529
Material316 stainless steel body, toughened glass optical chamber, silicone gasket and stainless steel fixings
Distribution/outputHighly efficient optical reflector system with adjustable lamp position
Lamp TypesHigh Pressure Sodium or Metal Halide
Lamp CapE40/ES
Lamp ChangeVia front cover
Cable Entry1 x M20 clearance hole
TerminalsTerminals block for up to 6mm2 conductors
Control GearCopper and iron ballast, timed impulse ignitor, pfc capacitor
OrientationHorizontal, beam down
MountingSide arm mounting – Ø34 to Ø42mm pole, other diameters on request
Supply220 to 254V 50/60Hz ac

ABTECH Avena ZONE 2 LIGHTING

LUMINAIRE RATINGS

Abtech Product ReferenceLamp
Type
Lamp
Cap
Power
(W)
Temperature
Rating
Ambient
Temperature
Weight
(kg)
LX2AVE100SHHPS or MHE40100WT4-50 to +55ºC8.5
LX2AVE150SHHPS or MHE40150WT4-50 to +55ºC8.5
LX2AVE250SHHPS or MHE40250WT3-50 to +55ºC9.8



Zone 2 Street Light Abtech Avena - Dimensions

Zone 2 Street Light Abtech Avena – Dimensions

HAZARDOUS AREA CERTIFICATION

Abtech Avena street lights are certified according to leading hazardous area classifications including:

  • Area Classification Zone 2 & 22, Gas and Dust
  • Type of Protection Ex nR (restricted breathing)
  • Apparatus Coding Ex nR IIC T* Gc, Ex tc IIIC T1350C Dc
  • Certificate Number AB 15ATEX4109X
