Hazloc Heaters BTX1-N-A Bi-metal Explosionproof Room Thermostat

Hazloc Heaters BTX1-N-A Bi-metal Explosionproof Room Thermostat



Hazloc BTX1-N-A is a bi-metal sensing explosionproof thermostat is suitable for heating and cooling applications such as heaters, exhaust fans and air conditioners with an IP66 rating and suitable for a hydrogen gas atmosphere (Zone Group IIB+H2) – BTX1 is available as a built in option on all sizes of the Hazloc XEU1 hazardous area heater.

The hazardous area thermostat has a temperature adjustment range of 5°C to 25°C, a fast acting bi-metal sensing plate that is unaffected by altitude, dial locking screw to prevent unwanted adjustments, phenolic thermal-break standoffs between the knob and base to prevent heat creep, two (3/4”NPT) openings for easy field wiring and can be field wired from either a vertical or horizontal orientation for flexibility of install.

Hazloc BTX1-N-A has an aluminium housing with no exposed copper or brass provides suitability for H2S environments making the explosionproof thermostats dependable, accurate and robust.

CSA Hazardous Area Thermostats

CSA Hazardous Area Thermostats

Hazloc Heaters BTX1-N-A

Explosionproof Thermostat Features

  • Bolted, removable cover provides instant access for installation and servicing
  • Dial locking screw prevents unwanted adjustments
  • Phenolic thermal-break standoffs between knob & base prevents heat creep
  • IP66/Type 4 ratings for moisture/dust protection
  • CFC & mercury free, no levelling required
  • Fast-acting, accurate, bi-metal sensing plate is unaffected by altitude
  • Two (3/4″ NPT) openings for easy field wiring (includes one 3/4″ plug)
  • Field wiring from either vertical or horizontal orientation for flexibility of install
  • Can be used to directly control small HP motors and resistive loads
  • Third party impact tested for ensured durability

Hazloc Heaters BTX1-N-A

Specification

Temperature adjustment range5°C to 25°C (40°F to 80°F)
Temperature differential+/- 1°C (1.8°F) from set point
Operating limits-50°C (58°F) ≤ T amb ≤ +40°C (104°F)
Storage limits-50°C to +60°C (-58°F to +140°F)
SwitchingSnap acting
Field wiring openingsTwo 3/4″ NPT (includes one 3/4″ plug)
Ingress protectionIP66/Type 4
Net weight1.5 Kg (3.3 Lbs)
Ship weight1.6 Kg (3.5 Lbs)
Shipping dimensions12.7 cm x 12.7 cm x 15.2 cm
(5″ x 5″ x 6″)

Hazardous Area Approvals & Protection Methods

  • Class I, Division 1 & 2, Groups C & D
  • Class II, Division 1, Groups E, F & G

    CSA Hazardous Area Thermostats

    CSA Hazardous Area Thermostats

  • Class II, Division 2, Groups F & G; Class III; T6
  • Class I, Zone 1, Ex db, Groups IIA, IIB, T6, Gb
  • Class I, Zone 2, Ex dc, Groups IIA, IIB, T6, Gc
  • Class I, Zone 1, AEx db, Groups IIA, IIB, T6, Gb
  • Class I, Zone 2, AEx dc, Groups IIA, IIB, T6, Gc
  • Class II, Zone 21, Ex tb, Groups IIIA, IIIB & IIIC, T85°C, Db
  • Class II, Zone 22, Ex tc, Groups IIIA, IIIB & IIIC, T85°C, Dc
  • Class II, Zone 21, AEx tb, Groups IIIA, IIIB & IIIC, T85°C, Db
  • Class II, Zone 22, AEx tc, Groups IIIA, IIIB & IIIC, T85°C, Dc
  • Flameproof:
    CSA 22.2 No. 30
    UL 1203
    CSA/UL 60079-1
  • Dust ignition proof:
    CSA 22.2 No. 25
    UL 1203
    CSA/UL 60079-31
  • Ingress protection (IP66/Type 4) :
    IEC 60529 CSA 22.2 No. 94
    UL 50
Hazloc Heaters BTX1-N-A - Physical Dimensions

Hazloc Heaters BTX1-N-A – Physical Dimensions
