HF6IBC-3 IBC Heating Jacket – 3KW 3000W

HF6IBC-3 IBC Heating Jacket - 3000W

HF6IBC-3 IBC Heating Jacket – 3000W

HF6IBC-3 IBC Heating Jacket

3KW

HF6IBC-3 IBC heater jackets are designed to provide efficient method of high temperature heating IBC’s via 2 x 1500W heating coils within a thermally insulated heater jacket made from a water-resistant, Teflon coated polyester, insulated with a layer of filament insulation.

The HF6IBC-3 heater jacket is fitted with a fully adjustable 0-90ºC thermostat and is also available with an insulation lid that not only significantly decreases heat up time but also increases maximum heated temperatures.

The HF6IBC-3 IBC heating jacket comes complete with quick release buckles and mounting hooks for ease of installation and removal.

The HF6IBC-3 is particularly suited for rapidly raising the temperature of an IBC and allows for the client to heat containers at the point of use or should the client need to move the IBC container the thermal insulation provided by the HF6IBC-3 heating jacket will help to maintain the heated temperature.

All IBC heater jackets are manufactured to conform to the EEC Low Voltage and EMC directives and CE marked accordingly. T&D also supply a full range of drum heater jackets to suit all container sizes and temperature applications.

HF6IBC-3 IBC Heating Jacket - 3000W

HF6IBC-3 IBC Heating Jacket – Key Features

HF6IBC-3 IBC Heating Jacket – Features & Benefits

  • Teflon/Polyester Insulation
  • IP40 Protection
  • 2 x 1500W Power Circuit
  • Thermally Insulated
  • Adjustable Quick Release Buckles
  • Easy Installation Hook Supports
  • Flap for Filler Access
  • 0ºC to 90ºC Adjustable Thermostat
  • Bespoke Sizes to Order
  • 4 Metre Power Cable
  • Ex-stock
  • 230V / 110V

HF6IBC-3 IBC Heating Jacket – Technical Specification

Part NumberHF6IBC23BHF6IBC13B
Size1000mm x 4400mm (3900mm Heated Length)
Rating230V110V
Heating Circuits2 x 1500W
Temperature Control0ºC to 90ºC Adjustable Thermostat
IBC Jacket MaterialHeated Face – Polyester Base Fabric Teflon Coated Outer Face – 1100 Deitex Texturised Nylon Polyurethane Coated
InsulationGlass Filament Blanket
Heating ElementSilicone Insulated Spiral Wound Resistance Element
Power Cable4 Metre HO7RN-F
FixingNylon Webbing With Quick Release Adjustable Buckles & 5 x Polypropylene Mounting Hooks
IP RatingIP40



T&D are also able to provide a range of ATEX certified insulated drum heaters & IBC heating jackets – we can specify, design and manufacture bespoke options where required.
