Zone 1 & Zone 2 Hazardous Area – Abtech LR52 LH Junction Box
Zone 1 & Zone 2 Hazardous Area – Abtech LR52 LH Box
Abtech LR52 LH box high voltage hazardous area electrical enclosures and junction boxes provide safe power distribution for 3.3kV systems up to 240sqmm cables – ATEX certified for Zone 1 and Zone 2 connection of HV cables in hazardous area locations.
HIGH VOLTAGE ENCLOSURE
ZONE 1 & ZONE 2 HAZARDOUS AREAS
ENCLOSURE APPLICATION
Abtech LR52 LH box high voltage enclosures are suitable for both industrial and hazardous areas.
Protection Degree IP66 or IP67.
HAZARDOUS AREA CERTIFICATION
High Voltage Enclosures & Junction Boxes (HV) – Hazardous Area
- ATEX EEx e (Zone 1 & Zone 2)
- NEMA 4X (CSA, UL & FM) Class 1 Division 2
- Deluge Tested To DTS-01
Zone 1 & 21, Gas and Dust / Class 1 Division 2
Type Of Explosion Protection – Ex e, Ex tb
Apparatus Hazardous Area Coding – Ex e IIC T4, Ex tb IIIC IP66 T650 C Db / Ex e IIC T3, Ex tb IIIC IP66 T80ºC Db
TEMPERATURE RATING
- Standard: -50° to +40°C (-58° to 104°F)
- Option: -50° to +55°C (-58° to 131°F)
Abtech LR Box General Arrangement HV Enclosure Drawing – cable termination, enclosure and junction box suitable for jointing, connecting and terminating HV cables 3.3kV.
Abtech LR52 Box ELECTRICAL Enclosures
Junction Box Specification
| Abtech Part Ref | Width (mm) Dimension X | Height (mm) Dimension Y | Depth (mm) Dimension Z | Maximum Voltage (kV) | Maximum Current (A) | Maximum Conductor Size (mm²) | Phase | Weight (kg) | Hazardous Area Enclosure  |
| LR52 LH | 510 | 510 | 220 | 3.3 | 1250 | 240 | 1 | 30 | Â Zone 1 & Zone 2 |
HV High Voltage Specialists – Zone 1 & Zone 2 Hazardous Area Certified By ATEX
