Sick PFT Pressure Measurement Sensors

SICK SENSORS

SICK PFT Pressure Measurement Sensors

  • Measuring ranges from 0 mbar … 100 mbar up to 0 bar … 600 bar
  • Relative, absolute, and ± measuring ranges
  • Also available with flush-mounted membrane
  • Process temperature up to 150 °C (optional)
  • Large number of commonly used process connections
  • High shock and vibration resistance
  • Accuracy 0.5% or 0.25%
  • Output signal 4 mA … 20 mA, 0 V … 5 V or 0 V … 10 V
  • Zero and span adjustable
  • Round connector M12 x 1, angled plug (DIN 175301-803 A) or cable connection

SICK PFT – BENEFITS

  • Reliable and highly accurate measurement technology
  • Wide application range
  • No mechanical wear, fatigue-proof, maintenance-free as no moving parts
  • Simple and cost-saving installation
  • Optimal solution for individual requirements due to very versatile configurability

The SICK PFT pressure measurement sensor is an electronic pressure transmitter used for the precision measurement of pressures in liquids and gases and is well suited to solve demanding measurement tasks in industrial applications.

The SICK PFT pressure measurement sensor is available with design variations with extended temperature range, enhanced measurement accuracy, or flush-mounted membrane open up a wide range of applications.



Device TypePressure Transmitter
Measuring rangeGauge Pressure:  0 bar … 0.1 bar up to 0 bar … 600 bar
Absolute Pressure: 0 bar … 0.25 bar up to 0 bar … 25 bar
Compound Pressure: -1 bar … 0 bar up to -1 … +30 bar
Pressure UnitBar, MPa, psi and kg/cm²
Accuracy≤ ± 0.5 % of the span
≤ ± 0.25 % of the span
Signal outputsAnalog
Electrical connectionRound Connector M12 x 1, Angled Plug, Cable Connection

Pressure monitoring of abrasive media in silicon cutting machine
Sick PFT Pressure Measurement Sensors

Thanks to a hermetically sealed stainless steel membrane, the SICK PFT pressure sensor operates in caustic environments with no long-term degradation. There are no moving parts to wear – virtually maintenance free!
