Industrial Plugs – Marechal 16A-250A Plugs & Sockets (Decontactors)
Industrial Plugs – Marechal 16A-250A Plugs and Sockets (Decontactors)
Hazardous Area Plugs ♦ High Current Plugs ♦ High Temperature Plugs ♦ ATEX
Marechal industrial plugs and sockets offer an extensive and comprehensive product range for all industrial electrical power applications with power currents varying from 16A to 250A with 1,000 volt power supply.
Industrial Plugs
Thorne & Derrick are Approved Main Distributors for Marechal Industrial Plugs – contact us for competitive prices, fast delivery and expert technical support to enable the selection and specification of the correct plug, socket or decontactor for all industrial and hazardous area power distribution applications.
A Decontactor® is a plug and socket outlet system with an integrated power switch permitting absolutely safe connection and disconnection of electrical equipment with plug-and-play simplicity.
Decontactors = Plug + Socket-Outlet + Motor Load Make/Break Switch. No ordinary plugs and sockets, Marechal Decontactors permit safe connection and disconnection of electrical equipment from live power supply, with no requirement for hard-wiring or contactor.
Marechal DSN Plugs
Compact & Watertight Decontactor
Marechal DSN
- Automatic IP66/IP67 water and dust tight decontactors
- AC-22 and AC-23 breaking capacity
- Impact-resistant GRP casing
- 20-63A plugs
- 500V-1000V plug and socket outlet
Marechal DS Plugs
Decontactor for Industry
Marechal DS
- Safe and simple connection up to 250A power distribution
- Safety shutter
- GRP or metal casing
- 30A-250A plugs
- 690V-1000V plug and socket outlet
Marechal DN Plugs
Robust Decontactor
Marechal DN
- Automatic IP54/IP55 water and dust tight
- Impact resistant metal casing
- Plugs suitable for heavy industry
- 20A-90A plugs
- 500V plug and socket outlet
Marechal PNC/PN Plugs
Compact Connectors & Plugs
Marechal PNC/PN Plugs
- GRP or metal casing
- Automatic IP66/IP67 water and dust tight
- Long life
- 16A-30A plugs
Marechal DB Motor Switch Connectors
Disconnectable Motor Switch
Marechal DB
- AC-3 switch for motors
- Automatic IP66/IP67 water and dust tight
- Impact resistant metal casing
- 7.5kW-45kW motor switches
- 40A-125A switches
Marechal Star-Delta Motor Connectors
7 Pole Decontactors & Connectors
Marechal Star-Delta Connectors
- Star-Delta start up
- Connecting motors with two operating speeds
- Simpler and safer than fixed wiring
- Star-delta connector designed to withstand high overloads
- 30A-50A
- 415V-500V connectors
Power Plugs For Industry
Visit our Blog to discover how Marechal decontactors provide safe and reliable low voltage power to all industries.
➡ For complete information, specifications and technical data about Marechal Industrial Plugs please refer to the product sections below – contact T&D to discuss applications for hazardous area plugs and sockets for potentially explosive atmospheres including Zone 1 & Zone 2.
Food & Beverage. Waterproof plugs (IP66 IP67) withstand high pressure cleaning, spray and humidity.
Oil & Gas. ATEX plugs certified for hazardous area Zones 1/2 (gas) and Zones 21/22 (dust).
Heavy Industry. Electrical power plugs up to 750A with safe disconnect under load.
Hazardous Area Plugs – Zone 1 & Zone 2 Plugs, Sockets & Connectors (Explosion Proof – ATEX & IECEx)
