The Abtech Gamma Flood/Lowbay is an LED floodlight/lowbay suitable for use in Zone 2 gas, Zone 21 and Zone 22 dust hazardous areas – fully ATEX and IECEx compliant. The Zone 2 flameproof floodlight utilises high output LED modules that combine to provide a crisp and consistently uniform white light.
Abtech LX2GAM4LB57 lighting enclosure is constructed from marine grade stainless steel for maximum corrosion resistance and is designed to operate at a wide range of ambient temperatures (-50 to +55 degrees C). The hazardous area floodlight also features a rear-mounted termination enclosure for simple installation.
Designed for the rigours of hazardous area operation, the Gamma Flood/Lowbay LED floodlight features built in harmonic and over voltage protection.
Abtech Gamma Flood/Lowbay Ex-rated LED luminaires minimise ongoing maintenance and are supported by our complete five-year system warranty.
Zone 2 LED Floodlight Hazardous Area ATEX IECEx Ex i – Abtech Gamma Flood Lowbay
Zone 2 LED Floodlight Hazardous Area ATEX IECEx Ex i
Features
- Part Number: Abtech LX2GAM4LB57
- High performance LED module providing uniform and crisp white light
- Stainless steel construction to ensure extended life in harsh conditions
- 5-year complete system warranty
- Compact design and flexible mounting allows the Gamma to also be used as a lowbay
| Luminaire Type | Zone 2 & 21, 22 LED Floodlight/Lowbay |
| Ingress Protection | IP66/67 to EN60529 |
| Ambient Temperature | -50oC to +55oC |
| Material | Stainless steel 316 grade housing, toughened glass window, silicone gaskets and stainless steel fixings |
| Lamp Types | Light emitting diode, pure white (5700K) |
| Colour Rendering Index | > 80 |
| LED Life | 50,000 hours L70 @ 50°C |
| Cable Entry | 2 x M20 clearance holes. Supplied with 1 x Ex plug and 1 x transit plug |
| Terminals | Looping terminal block for up to 4mm2 conductors |
| Control Gear | Electronic driver: EN60601-1 (CE), EN61204-3 (EMC), EN61000-4-5 (surge protection class 3). |
| Orientation | 0° to 120° |
| Mounting | Via saddle bracket |
| Supply | 110 to 254V 50/60Hz ac |
Zone 2 LED Floodlight Abtech Gamma Flood/Lowbay – Dimensions
| Part Number | Colour Temperature (K) | Lumen Output (lm) | Power (W) | Temp Class & Surface Temperature | Weight (kg) |
|||
| Tamb 55 ºC | Tamb 40 ºC | |||||||
| Abtech LX2GAM4LB57 | 5,700 | 13,675 | 96 | T3 | T100°C | T4 | T85ºC | 13 |
HAZARDOUS AREA CERTIFICATION
Abtech Gamma Flood/Lowbay LED floodlights are certified according to leading hazardous area classifications including:
- Hazardous Area Area Classification Zone 2, 21 & 22, Gas and Dust
- Type of Explosion Protection Ex nA (non-sparking), Ex tb & Ex tc (Dust)
- Apparatus Coding Ex nA IIC T* Gc, Ex tb IIIC T*°C Db and Ex tc IIIC T*°C Dc
- Certificate Number CML 15ATEX3045 (Zone 2 & 22), CML 15ATEX4042 (Zone 21) / IECEx CML15.0022
T&D, The Explosive Atmosphere Experts, provide a single-source capability for the most extensive range of Electrical, Mechanical, Process & Instrumentation Equipment suitable for hazardous area locations.
