Control Stations - Zone 2 Hazardous Area ATEX Certified For Dust Atmospheres

Control Stations – Zone 2 Hazardous Area ATEX Certified For Gas Atmospheres

Combustible and potentially explosive atmospheres include gases, mists, vapours and dusts – an explosive atmosphere can be created by the presence of flammable substances mixed with air, this is designated as a Zone 2 hazardous area.

ATEX category 2D Flammable Gas

Zone 2 Control Stations

Technor hazardous area control stations are ATEX certified (Group II) for safe use in Zone 2 potentially explosive atmospheres. Control stations can incorporate single or double push buttons, emergency push button and emergency stop start options – hazardous area “stop starts” are manufactured from GRP, Copper free aluminium or Stainless Steel and are designed to offer a flexible, light weight and cost effective solution tailor made upon customer request.

Zone 2 Hazardous area

Explosive gas atmosphere not likely to occur in normal operation but may be present for short periods

Bespoke Control Stations For Hazardous Areas

T&D’s in-house CAD drawing facilities produce hazardous area certified control stations for international oil, gas and petrochemical projects – ATEX certified for Zone 1, 2, 21 & 22 gas and dust atmospheres.

T&D assemble a wide range of “stop start” control station with multiple combinations and functions, this includes Zone 2 control stations – we also stock hazardous area enclosures for LV-HV power, control and instrumentation applications.

ATEX hazardous area zones for Gas

Potentially explosive gas atmospheres are categorised into 3 hazardous area zones, based upon the grade of explosion risk according to EN60079-10-2:2009.

ZONE 0 HAZARDOUS AREA

A place in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is present continuously or for long periods of time.

ZONE 1 HAZARDOUS AREA

A place in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is likely to occur in normal operation occasionally.

ZONE 2 HAZARDOUS AREA

A place in which an explosive atmosphere consisting of a mixture with air of flammable substances in the form of gas, vapour or mist is not likely to occur in normal operation but, if it does occur, persists for a short period only.

Technor hazardous area electrical equipment

For competitive pricing, delivery and technical support on the complete range of Technor Hazardous Area products, please contact T&D:

Lighting – Fluorescent, Wellglass, LED Lighting & Floodlights
Control Stations – Increased Safety & Flameproof
Junction Boxes – Increased Safety & Flameproof
Enclosures – Explosion Proof & Flameproof
Plugs & Sockets

Technor Hazardous Area Electrical Equipment

Technor Hazardous Area Equipment – T&D distribute electrical enclosures, lighting luminaires, electrical panels and control stations.

Isolators

Hazardous Area Isolators ATEX Zone 1 Zone 2

Craig & Derricott hazardous area isolators provide safe low voltage electrical isolation for Zone 1 and Zone 2 with Ex d (flameproof) and Ex e (increased safety) protection options.

➡ For complete technical information, hazardous area certification and product specifications about Zone 22 Isolators please see the product sections below.

Visit Zone 1 & Zone 2 Hazardous Area Isolators for further information about “stop start” and emergency control stations for potentially explosive gas and vapour atmospheres.
